Industrial Automation Products

ALLEN BRADLEY • RKD3466145

1494V-DH633-A
DISCONTINUED BY MANUFACTURER
DISCONNECT SWITCH
30 A
1494 SERIES
600 V MAX
W/O FUSE COVER
NORMALLY OPEN CONTACT
REPLACED BY 1494U-J30-CR-M-NO

ALLEN BRADLEY • RKD3466173

1494V-RA4
CONNECTING ROD
FOR VARIABLE DEPTH DISCONNECT SWITCH
9-1/8X21-5/8 INCH

ALLEN BRADLEY • RKD3466169

1494V-H13
ANTI-ROTATION KIT FOR SCREW

ALLEN BRADLEY • RKD3466141

1494U-PC2-IP20
1494U PROTECTIVE COVER IP20

ALLEN BRADLEY • RKD3466139

1494U-PC1
SHORT PROTECTIVE COVER
30 AMP - 100 AMP SWITCH
1494U

ALLEN BRADLEY • RKD3466133

1494U-LC200
COPPER
200 AMP
FOR USE ON 1494U DISCONNECT SWITCH
MOUNTABLE

ALLEN BRADLEY • RKD3466135

1494U-LM200
LUG CONNECTORS
COPPER
200A
MULTIPORT
FOR USE ON 1494U DISCONNECT SWITCH
(PACKAGE OF 3)

ALLEN BRADLEY • RKD3466105

1494-H1
DISCONTINUED BY MANUFACTURER
HANDLE FOR DISCONNECT
30/60/100 AMP

ALLEN BRADLEY • RKD3466090

1494F-L4
BULLETIN 1494
NEMA DISCONNECT SWITCHES
ACCESSORIES
DISCONNECT SWITCH
DOOR HARDWARE KIT
FOR GREATER THAN 48 INCH(1219MM)
TOP
SIDE
AND BOTTOM (RIGHT HAND)
DOOR HARDWARE KIT DOES NOT INCLUDE RECTANGULAR CONNECTING BARS (1/4 X 5/8 INCH)

ALLEN BRADLEY • RKD3466092

1494F-M1
DISCONNECT SWITCH HANDLE
SMALL
PAINTED METAL
TYPE 1/3R/4/12

ALLEN BRADLEY • RKD3466126

1494U-K31
HARDWARE KIT
VISIBLE BLADE SWITCH
30-100 AMP

ALLEN BRADLEY • RKD3466094

1494F-N21
INTERLOCK KIT
AUXILIARY DOOR
PROVIDES INTERLOCKING BETWEEN THE MASTER AND AUXILIARY DOORS OF THE SAME ENCLOSURE
FOR USE WITH 1494C
1494F
1494G
1494M AND 1494V DISCONNECT SWITCHES
SPECIFY ONE MASTER DOOR KIT AND AS MANY AUXILIARY DOOR KITS AS NECESS

ALLEN BRADLEY • RKD3466077

1494C-CMX5
CABLE MECHANISM
FOR 1494C DISCONNECT SWITCHES
LEFT-HAND
4 FT CABLE LENGTH
200 A SWITCH

ALLEN BRADLEY • RKD3466037

1492-W16S-RE
TERMINAL BLOCK
SCREW CONNECTION
SPACE SAVER
FEED THROUGH - SINGLE CIRCUIT
11 X 47.6 X 41MM (0.43 X 1.87 X 1.61 IN)
1 POLE
RED
VOLTAGE RATING UR - 600V AC/DC
CSA - 600V AC/DC
IEC - 800V AC/DC
ATEX - 550V AC/DC
MAXIMUM CURRENT
MOUNTABLE

ALLEN BRADLEY • RKD3466054

1492-WD4
TERMINAL BLOCK
SCREW CONNECTION
FEED THROUGH
2CIRCUIT
6 X 64 X 48.75 MM
0.24 X 2.52 X 1.92 IN
GRAY
20AMP
CSA 300VAC/DC
IEC 500VAC/DC
EEX E LL - 420V

ALLEN BRADLEY • RKD3466043

1492-W4-OR
TERMINAL BLOCK
1 POLE
ORANGE
SCREW CONNECTION
SPACE SAVER
FEED THROUGH - SINGLE CIRCUIT
6 X 45.3 X 35MM (0.24 X 1.78 X 1.38 IN)
VOLTAGE RATING UR - 600VAC/DC
CSA - 600VAC/DC
IEC - 800VAC/DC
ATEX - 550VAC/DC

ALLEN BRADLEY • RKD3466062

1492-WD6
TERMINAL BLOCK
SCREW CONNECTION
FEED THROUGH - TWO CIRCUIT
7 X 78 X 63.05 MM (0.28 X 3.08 X 2.48 IN)
1 POLE
GRAY
VOLTAGE RATING UR - 300V AC/DC
CSA - 300V AC/DC
IEC - 500V AC/DC
MAXIMUM CURRENT RATING UR - 50A
CSA - 55A
IEC

ALLEN BRADLEY • RKD3466072

1494C-CM2
CABLE MECHANISM
FOR RIGHT HAND SWITCH
4 FEET
30-100 AMP

ALLEN BRADLEY • RKD3466068

1492-WMG3-EACH
TERMINAL BLOCK
SCREW CONNECTION
MINI
SINGLE CIRCUIT - GROUNDING
6 X 21.4 X 24.5 MM (0.24 X 0.84 X 0.96 IN)
1 POLE
METALLIC
WIRE RANGE (RATED CROSS SECTION) IEC - #14 AWG (2.5 MM)

ALLEN BRADLEY • RKD3466064

1492-WG10
DISCONTINUED BY MANUFACTURER
TERMINAL BLOCK
10MM MAX
GREEN/YELLOW

ALLEN BRADLEY • RKD3466060

1492-WD4SS
DISCONTINUED BY MANUFACTURER
CIRCUIT BLOCK
FEEDTHROUGH
IEC
DOUBLE
SURGE SUPPRESSION
4 MM MAX. WIRE
GRAY

ALLEN BRADLEY • RKD3466066

1492-WKD6
TERMINAL BLOCK
SCREW CONNECTION
FEED THROUGH - KNIFE DISCONNECT
9 X 75.07 X 53.5MM (0.36 X 2.96 X 2.11 IN)
1 POLE
GRAY
VOLTAGE RATING UR - 600V AC/DC
CSA - 600V AC/DC
IEC - 800V AC/DC
MAXIMUM CURRENT RATING UR - 30A
CSA - 30A

ALLEN BRADLEY • RKD3466058

1492-WD4-RE
DISCONTINUED BY MANUFACTURER
IEC DOUBLE FEEDTHROUGH CIRCUIT BLOCK
STANDARD FEEDTHROUGH
4MM MAX. WIRE
RED

ALLEN BRADLEY • RKD3466056

1492-WD4-BL
DISCONTINUED BY MANUFACTURER
TERMINAL BLOCK
DOUBLE FEEDTHROUGH CIRCUIT BLOCK
20 AMP
STANDARD FEEDTHROUGH
4MM MAX. WIRE
BLACK
