Industrial Automation Products

WAGO • RKD3339172

285-495
TERMINAL BLOCK JUMPER
2WAY
ACCESSORY TYPE:JUMPER
FOR USE WITH:RAIL MOUNTED TERMINAL BLOCKS
NO. OF POSITIONS:2POSITIONS
PITCH SPACING:-
PRODUCT RANGE:-
COLOUR:GRAY ROHS COMPLIANT: YES

WAGO • RKD3339174

285-637
TERMINAL BLOCK
DIN RAIL
2POS
8-2AWG
PRODUCT RANGE:-
NO. OF CONTACTS:2CONTACTS
PITCH SPACING:-
CONNECTOR TYPE:-
CONNECTOR MOUNTING:DIN RAIL MOUNT
WIRE SIZE AWG MAX:8AWG
WIRE SIZE AWG MIN:2AWG
CONTACT PLATING:-
DEPTH:53MM ROHS COMPLIANT: YES

WAGO • RKD3339135

282-868
3-CONDUCTOR DISCONNECT TERMINAL BLOCK
E.G.
VOLTAGE TRANSFORMER CIRCUITS
WITH TOUCH-PROOF TEST SOCKET
FOR 4 MM Ø
TEST PLUGS
FOR DIN-RAIL 35 X 15 AND 35 X 7.5
6 MM²

CAGE CLAMP®

6
00 MM²

GREEN-YELLOW

WAGO • RKD3339155

283-907
TERMINAL BLOCK
2-CONDUCTOR GROUND
16 MM
CENTER MARKING
FOR DIN-RAIL 35 X 15 AND 35 X 7.5
CAGE CLAMP
16
00 MM
GREEN-YELLOW

WAGO • RKD3339161

285-157
TERMINAL BLOCK
2-CONDUCTOR GROUND
50 MM
LATERAL MARKER SLOTS
ONLY FOR DIN 35 X 15 RAIL
2.3 MM THICK
COPPER
POWER CAGE CLAMP
GREEN-YELLOW

WAGO • RKD3339115

282-104
2-CONDUCTOR THROUGH TERMINAL BLOCK
6 MM
SUITABLE FOR EX I APPLICATIONS
LATERAL MARKER SLOTS
FOR DIN-RAIL 35 X 15 AND 35 X 7.5
CAGE CLAMP
6
00 MM
BLUE

WAGO • RKD3339163

285-407
VOLTAGE TAP
HIGH CURRENT TERMINAL BLOCK
ACCESSORY TYPE:VOLTAGE TAP
FOR USE WITH:285-135 TERMINAL BLOCKS
PRODUCT RANGE:285 SERIES ROHS COMPLIANT: YES

WAGO • RKD3339159

284-684
3-CONDUCTOR THROUGH TERMINAL BLOCK
10 MM²

CENTER MARKING
FOR DIN-RAIL 35 X 15 AND 35 X 7.5
CAGE CLAMP®

10
00 MM²

BLUE

WAGO • RKD3339147

283-331
SEPARATOR PLATE
2 MM THICK
OVERSIZED
LIGHT GRAY

WAGO • RKD3339133

282-699
3-CONDUCTOR THROUGH TERMINAL BLOCK
6 MM²

WITH TEST OPTION
SAME PROFILE AS 3-CONDUCTOR DISCONNECT TERMINAL BLOCK
CENTER MARKING
FOR DIN-RAIL 35 X 15 AND 35 X 7.5
CAGE CLAMP®

6
00 MM²

GRAY

WAGO • RKD3339141

283-301
CONNECTOR ACCESSORY
GREY
END / INTERMEDIATE PLATE
RAIL MOUNTED TERMINAL BLOCKS

WAGO • RKD3339143

283-325
CONNECTOR ACCESSORY
16 MM
GREY
END / INTERMEDIATE PLATE
RAIL MOUNTED TERMINAL BLOCKS

WAGO • RKD3339139

283-104
2-CONDUCTOR THROUGH TERMINAL BLOCK
16 MM
LATERAL MARKER SLOTS
FOR DIN-RAIL 35 X 15 AND 35 X 7.5
CAGE CLAMP
16
00 MM
BLUE

WAGO • RKD3339113

281-684
THROUGH TERMINAL BLOCK
4 MM
3-CONDUCTOR
32 AMP
800 VAC
CAGE CLAMP CONNECTION
28-12 AWG
FRONT-ENTRY WIRING
BLUE
DIN RAIL MOUNT
-60 TO +105 DEGREES C

WAGO • RKD3339081

280-868
2-CONDUCTOR DISCONNECT/TEST TERMINAL BLOCK
WITH PIVOTING KNIFE DISCONNECT
WITH TEST PORT
GRAY DISCONNECT LINK
FOR DIN-RAIL 35 X 15 AND 35 X 7.5
2.5 MM²

CAGE CLAMP®

2
50 MM²

GRAY

WAGO • RKD3339137

282-870
3-CONDUCTOR DISCONNECT/TEST TERMINAL BLOCK
E.G.
CURRENT TRANSFORMER CIRCUITS
WITH TOUCH-PROOF TEST SOCKETS
FOR 4 MM TEST PLUGS
FOR DIN-RAIL 35 X 15 AND 35 X 7.5
6 MM
CAGE CLAMP
6
00 MM
GRAY

WAGO • RKD3339125

282-338
SEPARATOR PLATE
2 MM THICK
OVERSIZED
LIGHT GRAY

WAGO • RKD3339117

282-107
TERMINAL BLOCK
DIN RAIL
2 POSITION
24-10AWG
NO. OF POSITIONS:2POSITIONS
WIRE SIZE AWG MIN:24AWG
WIRE SIZE AWG MAX:10AWG
CONDUCTOR AREA CSA:6MM²

WIRE CONNECTION METHOD:CLAMP
RATED CURRENT:41A
RATED VOLTAGE:800V ROHS COMPLIANT: YES

WAGO • RKD3339131

282-604
2-CONDUCTOR THROUGH TERMINAL BLOCK
6 MM²

SUITABLE FOR EX I APPLICATIONS
LATERAL MARKER SLOTS
FOR DIN-RAIL 35 X 15 AND 35 X 7.5
CAGE CLAMP®

6
00 MM²

BLUE

WAGO • RKD3339127

282-339
END PLATE
RAIL MOUNTED TERMINAL BLOCK
FOR USE WITH:RAIL MOUNTED TERMINAL BLOCKS
ACCESSORY TYPE:END PLATE
PRODUCT RANGE:280 SERIES
COLOUR:ORANGE ROHS COMPLIANT: YES

WAGO • RKD3339119

282-325
END AND INTERMEDIATE PLATE
2.5 MM THICK
GRAY

WAGO • RKD3339091

280-907/999-950
2-CONDUCTOR GROUND TERMINAL BLOCK
2.5 MM²

SUITABLE FOR EX E II APPLICATIONS
CENTER MARKING
FOR DIN-RAIL 35 X 15 AND 35 X 7.5
CAGE CLAMP®

2
50 MM²

GREEN-YELLOW

WAGO • RKD3339111

281-633/281-410
COMPONENT TERMINAL BLOCK
DOUBLE-DECK
250 V
4 CONNECTION POINTS
4.00 MM CAGE CLAMP
GRAY
DIN RAIL MOUNT

WAGO • RKD3339103

281-345
END AND INTERMEDIATE PLATE
2.5 MM THICK
LIGHT GRAY
