Industrial Automation Products

SMC • RKD3014540

ZM131HF-K5LZ-M21L-Q
VACUUM EJECTOR
1.3MM NOZZLE DIAMETER
SINGLE UNIT:W/ VALVE+STANDARD SILENCER
SIDE/BOTTOM ENTRY
.5 MPA
G
SUPPLY (NC) &
RELEASE VALVE
DC: 1W
24 VDC
L PLUG CONNECTOR
.3M LEAD
W/ LIGHT/SURGE
1 OUTPUT - DIAPHRAGM - REED (AC/DC 100 VAC)
CE COMPLIANT

SMC • RKD3014511

ZL112A-K15MZ-DPML
MULTISTAGE EJECTOR
6MM SUPPLY
12 MM VACUUM
KPA
SILENCER
SUPPLY NC
RELEASE NC
24 VDC
M PLUG
300MM LEAD WIRE
W/ LIGHT/SURGE
NON-LOCKING PUSH
DIGITAL VACUUM PRESSURE SWITCH
PNP
1 OUTPUT
SI UNIT (KPA)
2M LEAD WIRE

SMC • RKD3014531

ZM071HF-K5LO-E55CL
VACUUM EJECTOR
0.7MM NOZZLE DIAMETER
SINGLE UNIT: W/ VALVE + STANDARD SILENCER
SIDE/BOTTOM ENTRY
.5 MPA
G
SUPPLY (NC) &
RELEASE VALVE
DC: 1 W (W/ INDICATOR LIGHT: 1.05 W)
24 VDC
L PLUG W/O CONNECTOR
W/O SUPPRESSOR
NON-LOCKING (PUSH)
1 OUTPUT

SMC • RKD3014522

ZL3H06-EBG
MULTISTAGE EJECTOR
W/O VALVE
300L/MIN(ANR)
.50MPA
RC3/4 8MM
VACUUM PRESSURE SWITCH( VACUUM 2 OUTS)
PNP
UNIT CONVERSION
2M LEAD WIRE W/ CONNECTOR

SMC • RKD3014517

ZL112-K15MZ-DPL
DISCONTINUED BY MANUFACTURER
MULTISTAGE EJECTOR
BUILT-IN SILENCER
SUPPLY + RELEASE VALVE
24 VDC
M PLUG
.3M LEAD WIRE
W/ LIGHT/SURGE SUPPRESSOR
NON-LOCKING (PUSH)
DIGITAL PRESSURE SWITCH
PNP
1 OUTPUT
UNIT SWITCHING FUNCTION
2M LEAD WIRE W/ CON

SMC • RKD3014525

ZM051H-J5LB-E14C
DISCONTINUED BY MANUFACTURER
VACUUM EJECTOR
.5MM NOZZLE DIAMETER
SINGLE UNIT: W/ VALVE + STANDARD SILENCER
SIDE/BOTTOM ENTRY
.5 MPA
RC
SUPPLY VALVE (NC)
DC: 1 W (W/ INDICATOR LIGHT: 1.05 W)
24 VDC
L PLUG CONNECTOR
.3M LEAD WIRE
W/O SUPPRESSOR

SMC • RKD3014520

ZL212-SP01
DISCONTINUED BY MANUFACTURER
KIT
FILTER ELEMENT
MULTISTAGE EJECTOR
ZL212 SERIES

SMC • RKD3014508

ZL112A-FE1-A
FILTER ELEMENT
VACUUM EJECTOR
ZL112A SERIES

SMC • RKD3014503

ZK2Q00R5NC1A-06
VACUUM EJECTOR W/ VALVE
SELF-HOLDING RELEASE VALVE + RELEASE (NC)
24 VDC
W/O PRESSURE SWITCH FOR VACUUM/SENSOR
COMMON WIRING PLUG-IN W/O LEAD WIRE
6MM PORT SIZE

SMC • RKD3014479

ZH20DS-12-16-16
DISCONTINUED BY MANUFACTURER
VACUUM EJECTOR
BODY PORTED
20MM NOZZLE
-88KPA 85L/MIN
ZH SERIES

SMC • RKD3014514

ZL112-K15GZ
MULTISTAGE EJECTOR
BUILT-IN SILENCER
SUPPLY + RELEASE VALVE
24 VDC
GROMMET
.3M LEAD WIRE
W/ LIGHT/SURGE SUPPRESSOR
NON-LOCKING (PUSH)

SMC • RKD3014497

ZK2F15K5KW-06
VACUUM EJECTOR W/ VALVE
MANIFOLD + INDIVIDUAL PORT EXHAUST
1.5MM
SUPPLY (NC) + RELEASE (NC)
24 VDC
DIGITAL PRESSURE SWITCH W/ ENERGY SAVING
-100 TO 100 KPA - NPN 1 OUTPUT - UNIT SELECTION
L PLUG W/ LEAD WIRE FOR SWITCH W/ ENERGY SAVING
6MM PORT SI

SMC • RKD3014500

ZK2-LVW-A
DISCONTINUED BY MANUFACTURER
VACUUM EJECTOR
AIR
INERT GAS
ZM NO SIZE RATING
CONNECTOR

SMC • RKD3014494

ZK2C10K5CL-06
DISCONTINUED BY MANUFACTURER
VACUUM EJECTOR W/VALVE
MANIFOLD + COMPLEX EXHAUST
1.0MM
SUPPLY NC + RELEASE NC
24 VDC
DIGITAL PRESSURE SWITCH
0 TO -101 KPA-PNP 2 OUTS-UNIT SELECTION
L PLUG + LEAD FOR VALVE 300MM+ LEAD FOR SWITCH/SENSOR
6MM PORT SIZE

SMC • RKD3014485

ZK2A12K5PL-08
VACUUM EJECTOR W/ VALVE
SINGLE UNIT + SILENCER EXHAUST
1.2MM
SUPPLY (NC) + RELEASE (NC)
24 VDC
PRESSURE SENSOR
0 TO -101 KPA-ANALOG OUTPUT 1 TO 5V
L PLUG CONNECTOR W/ LEAD FOR VALVE+SWITCH+SENSOR
8MM PORT SIZE

SMC • RKD3014491

ZK2C10A5MOZRWA-06-X211
VACUUM EJECTOR
ZK2 SERIES
MANIFOLD + COMPLEX EXHAUST
1.0MM
6MM PORT SIZE
MADE TO ORDER

SMC • RKD3014482

ZHI05D
VALVE VACUUM EJECTOR PORTED TYPE BODY 1/8IN BORE

SMC • RKD3014488

ZK2B12K5EL-06-B
VACUUM EJECTOR W/ VALVE
SINGLE UNIT + PORT EXHAUST
1.2MM
SUPPLY (NC) + RELEASE (NC)
24 VDC
PRESSURE SWITCH
-100 TO 100 KPA-NPN 2 OUTS
L PLUG CONNECTOR W/ LEAD FOR VALVE+SWITCH+SENSOR
6MM PORT SIZE
W/ BRACKET FOR MOUNTING SINGLE UNIT

SMC • RKD3014477

ZH13DS-01-02-02
DISCONTINUED BY MANUFACTURER
VACUUM EJECTOR
TYPE S
BODY PORTED TYPE
W/O SILENCER
SCREW-IN CONN
1.3 MM NOZZLE DIA
-88 KPA MAX VAC PRES
40 ANR/MIN MAX SUCTION FLOW RATE
78 ANR/MIN AIR CONSUMPTION
SUP CONN: 1/8 IN
VAC CONN 1/4 IN
EXH CONN 1/4 IN

SMC • RKD3014472

ZH13DL-01-02-02
ZH
VACUUM EJECTOR
BOX STYLE/BODY PORTED STYLE

SMC • RKD3014466

ZH13BL-01-02
DISCONTINUED BY MANUFACTURER
VACUUM EJECTOR
BOX STYLE/BODY PORTED STYLE
VACUUM PRESSURE : -48KPA{-360MMHG}
BUILT-IN SILENCER

SMC • RKD3014464

ZFC-EL016
FILTER
VACUUM FILTER
ZFA
ZFB
ZFC
ZFH

SMC • RKD3014469

ZH13BSA-08-F02
VACUUM EJECTOR
BOX TYPE
BUILT IN SILENCER
BODY PORTED STYLE

SMC • RKD3014455

ZCUKC32-50D
CYLINDER
FREE MOUNT FOR VACUUM
