Industrial Automation Products

ALLEN BRADLEY • RKD3372979

802B-CSAAXSXD4
COMPACT LIMIT SWITCH
ROTARY ARM
1 CIRCUIT
STANDARD CONTACTS
1 NO / 1 NC
CLOCKWISE &
COUNTER CLOCKWISE
CAST FRONT ROLLER LEVER
1.84 IN.
STEEL
0.69 IN.
0.28 IN.
METAL
FULL SWITCH (HEAD &
BODY)
10C
70C
2 LB IN
SPRING RETURN
4 PIN DC MICRO

ALLEN BRADLEY • RKD3372975

801-NX8
LIMIT SWITCH
CUSTOM
SAME AS 801 CM0Z1
LESS OPERATING LEVER
600V MAX
AC/DC

ALLEN BRADLEY • RKD3372959

801-ASN21
LIMIT SWITCH
GENERAL PURPOSE
ROLLER LEVER TYPE
SNAP ACTION
SPRING RETURN
TYPE 2 HOUSING STYLE
ARRANGEMENT N

ALLEN BRADLEY • RKD3372970

801-DSK145
LIMIT SWITCH
GENERAL PURPOSE
ENCLOSURE STYLE: NEMA TYPE 4 ENCLOSURE
LEVER TYPE: ROD OR CHAIN
CONTACT OPERATION: SLOW ACTION
SPRING RETURN

ALLEN BRADLEY • RKD3372973

801-NX10
LIMIT SWITCH
CUSTOM
SAME AS 801 CMN21 EXCEPT LESS OPERATING LEVER
120V / 6 AMP
600V / 1.2 AMP
AC/DC
MOUNTABLE

BABBITT • RKD3372968

LS7000-115VAC-S-36
LEVEL SENSOR
TIME DELAY SELECTABLE ON OR OFF
ADJUSTABLE 1/8 SECOND TO 2 HOURS
POWER: 115VAC - 2 WATTS
OUTPUT: 2 FORM C CONTACTS
DPDT
5 AMP RESISTIVE @ 125 VAC
FAIL-SAFE: HIGH OR LOW
RF FREQUENCY: 1.3 MHZ

ALLEN BRADLEY • RKD3372964

801-BSC28
801-BSC28
LIMIT SWITCH
600VAC-DC MAX

ALLEN BRADLEY • RKD3372966

801-DMC21
LIMIT SWITCH
GENERAL PURPOSE
NEMA 9 HOUSING STYLE
ROD OR CHAIN LEVER
1 NOC &
3 NCC
SNAP ACTION MAINTAINED
NEMA 1 ENCLOSURE
21
10.0N (2.25 LBS)
MAINTAINED
20.6 MM (0.81IN)

ALLEN BRADLEY • RKD3372956

801-ASC29
LIMIT SWITCH
GENERAL PURPOSE
ROLLER LEVER TYPE
SNAP ACTION
SPRING RETURN
TYPE 6 HOUSING STYLE
ARRANGEMENT C

ALLEN BRADLEY • RKD3372951

801-ASC218
GENERAL PURPOSE LIMIT SWITCH
NEMA 7 HOUSING STYLE
ROLLER LEVER
1 NOC &
3 NCC
RATCHET TYPE MAINTAINED
NEMA 1 ENCLOSURE
218
28.92N (6.5 LBS)
SPRING RETURN
12 DEGREES
68 DEGREES

ALLEN BRADLEY • RKD3372962

801BSB1-3
DISCONTINUED BY MANUFACTURER
LIMIT SWITCH
PUSH TYPE
1 NC
60 VAC

ALLEN BRADLEY • RKD3372954

801-ASC25
GENERAL PURPOSE LIMIT SWITCH
NEMA 3 HOUSING STYLE
ROLLER LEVER
1 NOC &
3 NCC
SNAP ACTION SPRING RETURN
NEMA 1 ENCLOSURE
25
17.8N (4.0 LBS)
SPRING RET

ALLEN BRADLEY • RKD3372946

801-AMC211
GENERAL PURPOSE LIMIT SWITCH
NEMA 19 HOUSING STYLE
ROLLER LEVER
1 NOC &
3 NCC
SNAP ACTION MAINTAINED
NEMA 1 ENCLOSURE
211
10.0N (2.25 LBS)
MAINTAINED

ALLEN BRADLEY • RKD3372949

801-ASB11
GENERAL PURPOSE LIMIT SWITCH
NEMA 11 HOUSING STYLE
ROLLER LEVER
1 NORMALLY CLOSED CONTACT
SLOW ACTION SPRING RETURN
NEMA 1 ENCLOSURE
11
15.58N (3.5 LBS)
SPRING RETURN
8 DEGREES
3 DEGREES

BABBITT • RKD3372941

LS7000-115VAC-PS
LEVEL SWITCH
115VAC (+/- 15%) 50/60HZ
CAST ALUMINUM ENCLOSURE
EXPLOSION PROOF
RF FREQ APPROX 1.3 MHZ

BABBITT • RKD3372911

LS6000-115VAC--S24
LEVEL SWITCH
115 VAC
316SS
24 INCH PROBE
5 AMP DPDT RELAY
BUILT-IN FUSE
1 INCH NPT CONNECTION
4 INCH LONG INSULATOR

ALLEN BRADLEY • RKD3372905

800Z-GF3
DISCONTINUED BY MANUFACTURER
SPECIALTY PUSH BUTTON
100-240 VAC OUTPUT RELAY
30.5 MILLIMETER MOUNTING HOLE
4 WIRE
FLYING LEAD CONNECTION

ALLEN BRADLEY • RKD3372894

800T-XC14
DISCONTINUED BY MANUFACTURER
CONTACT BLOCK

ALLEN BRADLEY • RKD3372914

800Z-GP3124
DISCONTINUED BY MANUFACTURER
TOUCH BUTTON
30.5MM
TYPE 4/4X/13 IP66
ZERO-FORCE MOMENTARY GENE
10...30V DC
PNP (SOURCING) OUTPUT
32 FT CABLE

ALLEN BRADLEY • RKD3372907

800Z-GL3125
DISCONTINUED BY MANUFACTURER 11/30/2009
ZERO-FORCE
GENERAL PURPOSE TOUCH BUTTON
30.5 MM
TYPE 4/4X/13
IP66
10-40 VDC
20-30 VAC RELAY
30.5 MM MOUNTING
WITHOUT GUARD

ALLEN BRADLEY • RKD3372916

800Z-GP3124Y
DISCONTINUED BY MANUFACTURER
TOUCH BUTTON
ZERO FORCE
10-30VDC
24VDC
800MA
30.5MM
TYPE 4/4X/13 IP66
MOMENTARY GENE
PNP (SOURCING) OUTPUT
32 FT CABLE

ALLEN BRADLEY • RKD3372903

800Z-GF2125Y
DISCONTINUED BY MANUFACTURER 2009-11-29
GENERAL PURPOSE TOUCH BUTTON
22.5MM
TYPE 4/4X/13 IP66
ZERO-FORCE MOMENTARY
85-264V AC
RELAY OUTPUT
22.5 MM MOUNTING
YELLOW GUARD

ALLEN BRADLEY • RKD3372909

800Z-GN3Q4B
DISCONTINUED BY MANUFACTURER
MOMENTARY PUSH BUTTON
BLACK GUARD
4 PIN QD
NPN OUTPUT
10-30 VDC
30.5 MM MOUNT

ALLEN BRADLEY • RKD3372901

800T-XH4
DISCONTINUED BY MANUFACTURER
CONTACT BLOCK
